SCBIMV-S
Ultra-compact size, flat spray – Liquid siphon type
Flat spray pneumatic nozzle producing fine atomization with a mean droplet diameter of 100 μm or less.**
Ultra-compact size. About 42 mm in total length including control adaptor.
Features large turn-down ratio under liquid pressures of 0.1 – 0.3 MPa (ca. 1 bar – 3 bar).
Produces two different spray distributions: uniform spray distribution throughout spray pattern area (when spraying at a low air-water ratio), or a mountain-shaped distribution having gradually tapered edges (at a high air-water ratio).
Capable of spraying smallest flow rate among all of our pneumatic spray nozzles.
Specifications
Pipe connection size
M3
Spray angle
80 ° -
80 °
Droplet size
Fine fog (10-100 µm)
Air pressure
-
Standard pressure
0 bar -
0 bar
Spray capacity
0,1 L/min -
0,74 L/min
Free passage diameter
0.5 -2.0 mm
Air consumption
3,75 L/min -
12,5 L/min
Applications
Spraying
Spraying: Mold release agent, lubricant, deodorant (trash pit, refuse collector, inlet conduit), oil, surface treatment agent, rust preventive, insecticide, aqueous urea, etc.
Cooling
Cooling: Dies, gas, glass, steel plates, steel pieces, moldings, automobile bodies, plastic products, etc.
Humidification
Moisture control: Paper, gas, ceramics, concrete, etc.
