VVEP-HL
Even flat spray with a large turndown ratio
Even flat spray nozzles with al large turndown ratio of spray flow-rate.
Maintains even distribution while minimizing variation in spray angle even when spray pressure is changed.
Having a large turndown ratio, this nozzle is optimal for applications where spray capacity needs to be changed depending on th
Specifications
Pipe connection size
R1/2, R1/4, R3/8
Spray angle
100 ° -
100 °
Droplet size
Light rain (0.3 - 1.0 mm)
Air pressure
-
Standard pressure
0,5 bar -
20 bar
Spray capacity
0,9 L/min -
185 L/min
Free passage diameter
-
Air consumption
-
Applications
Cleaning
Cleaning: Steel plate cleaning after pickling Other: Applications which require a large turndown ratio
Cooling
Cooling: Steel plates (upper zone and right under molding of continuous casting machines, etc.), casted steel, cast metal, extruded aluminum
