Rotating 3D cleaning with 2 or 4 nozzle arms

JA-3D/D180° series

JA-3D/D180° series

Features

The JA-3D/D180° series tank cleaner’s features:

  • Rotating nozzles for 3-Dimensional cleaning.
  • Spraying 180° downwards, and no scattering of water upwards. Ideal for tank cleaning with no upper lid.
  • Rotation is driven solely by the spray reaction force.
  • All supplied water is used as driving force and cleaning water. Minimal energy loss.
  • Nozzle mounts are available in two arms or four arms.
  • Applicable tank size is up to nine meters in diameter.

*1) Spray capacity is 12 – 36 L/min (two-arm type), or 24 – 70 L/min (four-arm type) each at 1.0–3.0 MPa (ca. 10 – 30 bar).

  Download CAD model   Contact us

Pipe conn. size

Rc 1/2"

Rated pressure

1.0 - 3.0 MPa (ca. 10 - 30 bar)

Spray capacity

12 - 70 L/min (*1)

Reach distance

6 - 9 m in diameter

Cleaning distance

Max. 9 m

Max. allowable temperature

4 - 60°C (40 - 140°F)

Applications

The JA-3D/D180° series tank cleaner has multiple applications:

  • Cleaning of tanks, containers, and conveyors
