Pneumatic slit laminar spray nozzle
PSN series
Features
The PSN series nozzles’ features:
- Pneumatic slit-laminar nozzle with uniform spray distribution throughout the entire spray pattern area.
- While multiple-nozzle alignment of conventional pneumatic spray nozzles leaves some spots unwashed, PSN nozzles provide uniform spray distribution and achieve a complete cleaning, leaving no spot unwashed. PSN can be used at a short distance.
*1) Measured at compressed air pressure of 0.1 – 0.4 MPa (ca . 1 bar – 4 bar) and liquid pressure of 0.1 – 0.4 MPa (ca . 1 bar – 4 bar) for PSN nozzle with slit length of 1000 mm and slit opening of 0.05 mm.
Thread standard
-
Pipe conn. size
Rc 3/8"
Standard pressure
-
Spray angle
-
Spray capacity
8.0 - 28.0 L/min (*1)
Supply air type
Compressed air
Liquid feeding system
Liquid pressure
Mean droplet diameter
-
Air consumption
520 - 1,700 L/min, Normal (*1)
Air pressure
-
Free passage diameter
-
Applications
The PSN series nozzles have multiple applications:
- Cleaning: Glass substrate, liquid crystal
- Cooling: Steel plates, moldings
- Moisture control: Paper, cardboard
- Surface finish process: Precision cleaning for steel surface treatment, Roll cleaning
